1971 Z28


This is supposed to be a M22 transmission from a 1971 Z28. The last six digits matches the VIN of the car. How come it looks like the partial VIN begins with two 7´s ?

http://i436.photobucket.com/albums/q...s-resan086.jpg

Re: 1971 Z28


Original paint I believe.

http://i436.photobucket.com/albums/q...s-resan094.jpg

http://i436.photobucket.com/albums/q...s-resan097.jpg

Re: 1971 Z28


Is the engine with the car? If so, what does the engine pad VIN stamp look like? It does look like 2 7's.

Re: 1971 Z28


This car is very original but was raced in the seventies, and the engine is not the "born with"-engine.

Re: 1971 Z28


www.nastyz28.com is the place for 2nd gen q&a

that trans has not been re-stamped if that is what you are asking ...

Re: 1971 Z28


I´m pretty sure that is the original trans for that car, but the stamp sure looks odd. Are you saying that it´s a commonly seen "mistake" ?

Re: 1971 Z28


yes

I think they were trying to stamp ones ( 1 's ):

http://i8.photobucket.com/albums/a26...unciestamp.jpg

http://i8.photobucket.com/albums/a26...iestampvin.jpg

Here is the info on decoding a Muncie:

http://www.5speeds.com/muncie2.htm

Re: 1971 Z28


P1C05C =

P = Muncie
1 = 1971
C05 = March 5
C= M22

Re: 1971 Z28


It does look like they were trying to stamp "1's" and used a 7 at an angle to get the result. I would say those are the original stampings.

Re: 1971 Z28


[ QUOTE ]
yes

I think they were trying to stamp ones ( 1 's ):

http://i8.photobucket.com/albums/a26...unciestamp.jpg



[/ QUOTE ]

Wow, that guy was having some anger management "issues" that day at the plant. https://www.yenko.net/ubbthreads/imag...emlins/eek.gif

Re: 1971 Z28


How about some more pics of the car.

Re: 1971 Z28


It was sitting there dusty with the engine out of the car so I didn´t take many pics of it. I was just looking for proof of it being an original M22 Z28 car.

http://i436.photobucket.com/albums/q...s-resan085.jpg

http://i436.photobucket.com/albums/q...s-resan099.jpg

Re: 1971 Z28


Anders, did you find it on your tour last weekend?


Jan

Re: 1971 Z28


Here is another solid 40.000 miles 1971 Z28 I looked at last weekend. This one now has a LS7 engine backed up by a M22 trans, but the original LT1 and M21 trans is safe on a pallet. I believe the engine, trans, and rearend had never been apart. The original hood is also in safe storage.
It has the one-piece rearspoiler just like the blue one.
That is a New York state inspection certificate from january 1974, in the windshield.

http://i436.photobucket.com/albums/q...s-resan044.jpg

Re: 1971 Z28


Yes I did, Janne. They are out there !

https://www.yenko.net/ubbthreads/imag...ins/3gears.gif https://www.yenko.net/ubbthreads/imag...ins/3gears.gif

Thanks for the tea and sandwiches by the way, Janne. https://www.yenko.net/ubbthreads/imag...iggthumpup.gif

Re: 1971 Z28


[ QUOTE ]
It was sitting there dusty with the engine out of the car so I didn´t take many pics of it. I was just looking for proof of it being an original M22 Z28 car.



[/ QUOTE ]

It is, the vins match, the trans is real

the short spoiler was standard in 71, the larger one was optional
