1966 Chateau Slate L78 Chevelle

[OneStopRestoration]

Originally Posted by MYSTERYCHEVELLE

Looking good!! Now get those carpet slits made for the track claws while its naked in there

Mike I appreciate you looking out for me on the details but this is one area on my restorations I throw originality out the window. I have always placed the seat tracks on top the carpet. I know this car had the carpet replaced at one time so I really cant say for sure how it came. I did find carpet under the feet of the seat tracks but so many things can happen to a car in its lifetime.

[67since67]

Great detailing going on here!!
If I may ask, who are you using for aluminum anodizing? - Bill W

[OneStopRestoration]

PM Sent Bill

[OneStopRestoration]

I also got the Grille back this week from the platter. Alot of taping. This was an original grill so not in perfect condition. I had to fill in some pits in the face area before painting with SEMs trim black. With the redone emblem it came out really nice.

[OneStopRestoration]

Put on the rocker trim this weekend. Have several originals to see how the factory very thinly painted the lines. Lots of masking and like 3 mins of painting. I have another 66 SS waiting on restoration that had the original pieces un touched with the factory screws shown below. There chromed #8s with a very low profile. Very similar to a wheel well molding screw, but a slightly smaller head diameter. In fact AMK has a screw pretty close to this that I used.

[OneStopRestoration]

I used NOS pieces for the side mouldings. As a piece of advice to avoid issues its best to fill all the holes the factory puts in and place your own. Couple of shots below of the drivers side. I rolled the car out of the garage today to clean things up. Car is finally starting to look really good. Just a piece of unique information comparing 66 to 67. I had original shots of the screws and clips, the screws are #8s of my car. I got confused because over the years I have robbed plenty of the these clips and thought the screws were #10s. Come to find out in the AIM 66 did use a #8 and 67 and I assume later used #10s.

[dykstra]

Gorgeous!!!

[OneStopRestoration]

My dad stopped over last weekend and we tackled putting on our first 66/67 top. Turned out very well. We started with gluing a small strip down the middle after centering everything up, and then we just worked one side at a time and then the sail panel areas. Little heat in the tight corners where the material struggles to stick helps alot.

I also worked on side glass quarter window trims and weather seals.

[mockingbird812]

Handsome!!! Nice work!

[OneStopRestoration]

Once i got the quarter windows adjusted to the front door windows I finished up the door panels. Still waiting on the arm rests, and front buckets. Backseat and belts all went in. Not much left to do at this point.

I think i may check out till fall on car progress. Ive been back and forth with the bumper because the front came back so out of wack. I ordered tires the other day and its Oct before they are expected to come in. Thanks all for following along. Once I get the car completely finished I will post later this year. Im considering showing the car at Chevelles in the Smokies. Im not sure I can catch MCACN this year.
